NSN 5975-00-258-2428
Part Details | ELECTRICAL CONDUIT CROSS
5975-00-258-2428 A type of electrical conduit fitting fabricated in the form of a cross having four hubs in the same plane, the axes of which form a right angle, and primarily intended to join electrical conduits and/or conduit fittings. For items of this type having ties for mounting wiring devices, see CONDUIT OUTLET.
Alternate Parts: 33672B1, 3367-2B1, 0181003010, 018-1003-010, 0181003010, 018-1003-010, 5975-00-258-2428, 00-258-2428, 5975002582428, 002582428
| Supply Group (FSG) | NSN Assigned | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | JUL 04, 1973 | 00-258-2428 | 13734 ( CROSS, ELECTRICAL CONDUIT ) |
REFERENCE DRAWINGS & PICTURES
STANDARD
Cross Reference | NSN 5975-00-258-2428
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 3367-2B1 | 30463 | DCX-CHOL ENTERPRISES, INC.DBA ELECSYS DIVISION OF DCX-CHOL |
| 018-1003-010 | 13499 | ROCKWELL COLLINS, INC.DBA GOVERNMENT SYSTEMS |
| 018-1003-010 | 95105 | ROCKWELL COLLINS, INC.DIV GOVERNMENT SYSTEMS - DALLAS |
Technical Data | NSN 5975-00-258-2428
| Characteristic | Specifications |
|---|---|
| STYLE DESIGNATOR | STANDARD |
| OVERALL LENGTH | 1.760 INCHES NOMINAL |
| MATERIAL | BRASS |
| SURFACE TREATMENT | CADMIUM |
| SURFACE TREATMENT DOCUMENT AND CLASSIFICATION | QQ-P-416,TYPE 2,CLASS 3 FED SPEC SINGLE TREATMENT RESPONSE |
